PANIO KF08U 8-Port PS/2&USB Combo Free A+ KVM Switch

PANIO offers an ideal enterprise 8 ports KVM switch solution for company server room or testing
facilities.PANIO Combo Free A+ 8 ports USB & PS/2 KVM switches feature the patented design of the
availability of USB & PS/2 interface connection, user friendly OSD utility, Daisy chain function, and the
flexibility of Firmware-Upgradable function.


Console your Keyboard/Mouse via PS/2 and/or USB at will.
Connect computers via PS/2 and/or USB at will.
Supports Windows 98SE/ME/2000/XP/Vista/7/2003 Server, Linux, Mac OS9/OSX and Sun Micro System
On-Screen-Display (OSD) & Cascade Chain functions.
OSD is intuitive menus driven for quick and efficient navigation.
Supports Daisy chain with 3 level cascades: up to 3 levels; control up to 64/256/4096 PCs, from a single console; cascaded units don't need special configuration.
Emulates PS/2 or USB keyboard on each PC to allow your computers to boot normally without a keyboard error.
Supports hot-pluggable. All devices connected to the KVM can be added or removed at any time, without shutting the unit down.
Supports 3 types of switching:
Hardware Push Button.
Hot-Keys on PS/2 and/or USB of keyboard.
Menu driven OSD (On Screen Display).
Supports Auto-Scan function to switch video inputs automatically among computers in preset intervals sequentially by OSD menu driven.
Supports LED display for PC and/or server status monitoring.
Supports VGA resolutions up to 2048 x 1536.
Supports Beeper during Switching enabled.
Fully compliant with the USB 1.1/ 2.0 specification.
Rack Mountable in 19” system tack (1U).
KVM firmware is upgradeable via on-board mini-USB download connector and external mini-programmer.
Patent No. TW M 284961, DE 20 2006 002 295.3, ZL 2005 2 0132700.2




1 x KF08U
8 x Custom combo 4-in-1 cable-1.8m (PS/2+USB KVM Cable)
1 x Rack Mount Kit
1 x Power adaptor
1 x User’s Manual


Model/Function KF08U
Number Of Computers Controlled 8
Selection Method Push Button and Hot-Key (PS/2 / USB Keyboard) Or On-Screen-Display (OSD)
LEDs Red for PC Selection Green for PC On-Line ready
PC Connectors Video 8 x HDB-15 female
(KB/MS) ( PS/2 & USB signal combined )
Console Ports Keyboard 1 x 6 pin mini-DIN female
Mouse 1 x 6 pin mini-DIN female
Video 1 x HDB-15 female
Keyboard 1 x USB – A type female
Mouse 1 x USB – A type female
Auto-Scan Interval Adjustable time setting by OSD menu driven
DDC, DDC2,DDC2B monitor Yes (Max. Resolution up to 2048 x1536 )
Hot Swappable Yes
Operating systems supported Windows 98SE/ME/2000/XP/Vista/7/2003 Server, Linux Mac OS9/OSX and Sun Micro System
Power By external power adaptor
Dimensions (L X W X H) 44 x 15.7 x 4.5 cm
Unit Weight 1750g
Housing material Metal
Operating Temperature 32~ 122 ° F (0~ 50 ° C )
Humidity 0%~80%RH
Firmware upgrade connector Mini USB female
