UE2300


2 port output USB2.0 network cable extender

Support POC power supply


Products / USB Extender

4K KVM network cable + fiber optic extender
Feature
  • USB2.0 keyboard and mouse can be extended up to 80 meters through Cat6 network cable.
  • Remote 2 x USB2.0 output.
  • It can connect 2 USB flash drives at the same time, and the maximum extension is 40 meters.
  • It can connect 1 USB flash drive and 1 keyboard or mouse at the same time, and the maximum extension is 60 meters.
  • Support POC unilateral power supply.
  • Support various USB peripheral devices such as keyboard and mouse, flash drives, cameras, USB touch screens, etc.

Specification

Model Name UE2300
Transmitter interface 1 × USB2.0, 1 x RJ-45
Receiver interface 2 × USB2.0, 1 x RJ-45
Extended distance Status of the receiver connected to 2 X USB2.0 interfaces: (Powered by RX POC, USB2.0 extension works more stably)

Connecting 2 X USB flash drives at the same time can extend the distance up to 40 meters. (Actually tested CAT6 network cable)

Connecting a USB flash drive can extend the distance up to 60 meters. (Actually tested CAT6 network cable)

Connecting a USB2.0 device and a keyboard or mouse to extend the distance up to 60 meters. (Actually tested CAT6 network cable)

Only one set of keyboard and mouse can be connected to a maximum distance of 80 meters. (Actually tested CAT6 network cable)
Power supply DC 12V 1A, Support POC power supply
Dimensions 125 x 84 x 25mm ( LxWxH ) Transmitter/ Receiver

Note:

  • Please use original factory certified USB2.0 cable.
  • To maintain quality stability, please use original factory-certified power adapters.
  • If you need to use it with other equipment, please be sure to inform us to avoid incompatibility problems.
  • Please use Cat6 standard network cable (8 cores fully connected).
  • It cannot be used with a network switch.

Package Contents

  • 1 X UE2300 Transmitter
  • 1 X UE2300 Receiver
  • 1 X DC 12V 1A
  • 1 X USB2.0 Cable
  • 1 X User manual
