HW2250K


Professional HDMI/DP Input Video Wall Processor

Supports 8K+ resolution input, audio separation output, and 90°/180° rotation


Products / Video Wall

TV Wall Resolution Support up to 7680 Pixels Wide

Configurations: 1x2 (3840x1080), 1x3 (5760x1080), 1x4 (7680x1080), 2x2 (3840x2160), 2x1 Vertical (2160x1920), 3x1 Vertical (3240x1920), 4x1 Vertical (4320x1920)

Extended Horizontal TV Wall Resolution up to 15,360 Pixels

Configurations: 1x6 (11,520x1080), 1x8 (15,360x1080), 2x3 (5760x2160), 3x2 (3840x3240), 3x3 (5760x3240), 3x4 (7680x3240), Achieved through multiple HW2250 units in combination.

Expanded Vertical TV Wall Resolution up to 12,960 Pixels

Configurations: 6x1 Vertical (6480x1920), 8x1 Vertical (8640x1920), 9x1 Vertical (9720x1920), 2x3 Vertical (2160x5760), 3x2 Vertical (3240x3840), 4x3 Vertical (4320x5760), Achieved through multiple HW2250 units in combination.

Dual Signal Inputs

Supports both HDMI and DisplayPort inputs.

4K 60Hz Input Support

Accepts high-resolution 4K 60Hz signals for superior image quality.

Flexible Screen Rotation

Supports individual screen rotation at 90°, 180°, and 270°.

Seamless Edge Compensation

Adjustable bezel compensation ensures a more natural and immersive viewing experience.

External Audio Output

Equipped with a 3.5mm audio output for external speaker connectivity.

4K 60hz video wall
Feature
  • Supports built-in 1x2, 1x3, 1x4, 2x2, 2x1, 3x1, and 4x1 video wall configurations.
  • Supports switching between 1 HDMI and 1 DP input interface.
  • Supports up to 3840x2160 60Hz and 7680x1080 input resolutions.
  • Enables individual screen rotation of 90°, 180°, and 270°.
  • Provides manual edge correction to eliminate image misalignment caused by display bezel variations during video wall setup.
  • Offers a 3.5mm audio output for discrete audio extraction.
  • True hardware design, plug and play, eliminating the need for extra software installation.
  • Delivers pixel-perfect, lossless, proportional, and distortion-free image display.
  • Control methods include remote control and panel-mounted buttons.
TAIWAN PANIO 4K

Specification

Model Name HW2250K
Input 1 x HDMI, 1 x DP
Output 4 x HDMI, 1 x 3.5mm
Input resolution 1920x1080, 1920x2160, 1920x3240, 1920x4320, 3840x1080, 3840x2160 60Hz, 5760x1080, 7680x1080
Output resolution Up to 1920x1080 60hz, 720p, 1920x1200
Splicing TV wall Supports vertical or horizontal 1x2 1x3 1x4 1x6 1x8 1x10 2x2 2x3 2x4...up to 16 TV wall.
Protocol standard Support HDMI2.0, HDCP
HDMI cable length Input and output can be connected to HDMI 4K cable up to 5 meters.
Control method Remote control, panel button
Power DC 12V/ 1.5A
Dimensions 223 x 104 x 27mm ( LxWxH )

Note:

  • Please use a 4K-certified cable for signal connection to ensure optimal performance.
  • It is advised against using uncertified serial switchers, distributors, or converters to prevent potential issues.
  • To ensure quality and stability, always use the original certified power adapter provided.
  • For shipping safety, the remote control battery is not included in the package.
  • If planning to use with other devices, please inform us in advance to ensure compatibility and avoid any mismatches.
  • The combined output and input length should not exceed 10 meters; for longer distances, it is recommended to use an optical HDMI cable for extension.

Package Contents

  • 1 X HW2250K
  • 1 X 12V 1.5A Adapter
  • 1 X Remote control (Battery not provided)
  • 1 X User manual
