CH8813K


4K 60Hz 8x8 Matrix Switch Video Wall Controller

Video Wall and Matrix Switcher Solutions


Products / Matrix Switch + Video Wall

8x8 Matrix Video Wall Controller

Seamless 8-Screen Video Wall Integration | 8 Input Sources

4K 60Hz Resolution

Input & Output Support up to 3840x2160@60Hz

Multifunctional audio and video signal processor

Enhance Your Viewing Experience with Advanced Video Wall and Matrix Switcher Solutions.

Quick switching

Experience seamless switching with our advanced technology, ensuring a 0-second fast display with no black screen. Perfect for professional presentations and home entertainment setups.

Synchronized video wall and single screen display

Example: Displaying across 2 independent screens and a 3x2 video wall, totaling 8 screens.

Audio output

Supports up to 8 Channels of 3.5mm Audio Output for External Speakers.

External sound input

Each input port offers a built-in 3.5mm audio jack, providing 8 total inputs for external audio integration with HDMI output.

Dual-Port Control Interface

Dual RS-232 interfaces enable effortless control of matrix video walls, and other devices.

Dual LAN ports with Web UI control

Upgrade your network management with our advanced device featuring dual LAN ports and a user-friendly Web UI control system.

Scene Shortcuts

Benefit from 40 customizable scene shortcuts to swiftly switch between different scenes.

APP control

Easily manage multiple devices from anywhere with our Android and iOS-compatible matrix switcher.

4K 60HZ Matrix switch with video wall
Feature
  • Elevate Your Visual Experience with a 8-Screen Video Wall Matrix Switcher.
  • Experience Seamless Matrix Switching with Support for 8 Sets of HDMI+Audio Inputs.
  • Supports up to 3840x2160 60Hz Resolution, Backward Compatible.
  • Support HDMI2.0, HDCP2.2.
  • Experience Seamless 0-Second Switching with No Black Screen Issues. Enjoy Instant, Real-Time, and Smooth Switching Effects!
  • Supports Multi-Screen Video Wall Splicing and Independent Single-Screen Display.
  • Equipping each input channel with EDID processing technology effectively resolves prevalent display issues, such as user dissatisfaction with screen quality, flickering, and complete lack of image output.
  • Offers 40 customizable scene presets for efficient workflow in various applications such as monitoring, conferencing, and exhibitions. Instantly switch between scenes with a simple shortcut.
  • The system adopts a dual-network and dual-control backup redundancy design, significantly enhancing network stability and reliability.
  • Featuring a quad-core, quad-link core chip, this device offers up to 32Gbps processing speeds for high-performance, reliable signal exchange.
  • This device features up/down scaling capabilities, effectively addressing the issue of inconsistent image resolutions.
  • Supports automatic scene saving in the event of a power outage and automatic memory restoration upon startup.
  • Supports independent audio input and separate output for improved sound management.
  • Multiple control options are available, including infrared remote control, TCP/IP network control, RS-232 serial control, and a dedicated mobile app.

Specification

Model Name CH8813K
Input 8 x HDMI, 8 x 3.5mm
Output 8 x HDMI, 8 x 3.5mm
Input resolution The maximum resolution is 3840x2160 @60Hz, backward compatible.
Stitching output resolution Output resolution: 4K 60Hz\ 4K 30Hz\ 1080P\ 720P\ 1366 x 768 60Hz
Color depth 8 10 12bit
Color space YCbCr, RGB
The video transmission distance (Max.) The total length of the HDMI cable, including both the input and output segments, is limited to 10 meters.
Control method Remote control, TCP/IP, RS-232, Button, APP
Power DC 12V/ 5A
Dimensions 480 x 280 x 67mm (LxWxH)
Weight 4.5Kg

Note:

  • To achieve optimal signal transmission, please use a certified 4K 60Hz HDMI cable.
  • The use of non-certified serial switchers, distributors, and converters may lead to compatibility issues, signal degradation, or equipment malfunctions.
  • In compliance with shipping safety regulations, the remote control battery is excluded.
  • For optimal system compatibility, please consult us before utilizing this device with other equipment.
  • The combined input and output cannot exceed 10 meters; for longer distances, we recommend using an optical HDMI cable for extension.

Package Contents

  • 1 X CH8813K
  • 1 X DC 12V/ 5A
  • 1 X Remote control (Battery not provided)
  • 1 X User manual
