16-port HDMI KVM switch

Support 4K 30Hz / USB2.0 device / IR / RS-232 / WEB


HK1601

Products / Switch

Feature
  • 1 set of 4K HDMI screen and USB keyboard and mouse to centrally manage 16 computer hosts.
  • Support resolution up to 3840X2160 30Hz.
  • Support Windows 95/98/2000/2003/NT/XP/WIN7/WIN8, Linux, Unix, MAC OS...
  • Built-in USB2.0 HUB, can connect to USB devices.
  • Support auto scan function (adjustable auto jump time).
  • Support remote control switch, keyboard hot key switch, key switch RS-232 IP switch.
  • Supports automatic signal detection function, which can automatically display the incoming signal and skip the signal that is closed.
  • Can be used with PANIO CK1020K to extend the on-screen keyboard and mouse to remote operation.
  • Can be installed on a 19-inch rack.

Specification

Model Name HK1601
Input port 16 x HDMI, 16 x USB2.0
Output port 1 x HDMI, 4 x USB2.0, 1 x 3 Pin RS-232, 1 x LAN
Video resolution (Max) 3840 X 2160 30Hz / 4K 30Hz
Control mode 1. Remote control switch 2. Hot key switch 3. Key switch 4. RS-232 control 5. IP command
Auto scan Adjustable seconds
Cable length It can be connected to a 28AWG HDMI cable up to 5 meters long. If it is beyond this length that recommends using extender.
Power supply AC 110V-240V 50/60HZ DC: 12V
Dimensions 481 X 142 X 44mm (LxWxH)
Item Weight 3Kg

Note:

  • Please use a certified HDMI and USB cable to connect the signal.
  • It is not recommended to serially switcher, distributor, converter, and so on that has not been certified by the factory.
  • To maintain quality stability, please use the original certified adapter.
  • If you need to use it with other devices, please be sure to inform us to avoid incompatibilities.
  • Due to shipping safety considerations, the remote control battery not provided.

Package Contents

  • 1 X HK1601
  • 1 x Remote control (Battery not provided) battery model: CR2025
  • 1 X 12V adapter
  • 2 X Rack accessories
  • 1 X User manual
