[ VP118A ] 8-Port VGA Splitter/Extender with Audio 60m
VP118A 8 ports VGA Splitter & Extender with Audio allows you to display up to 8 sets VGA monitors and Stereo Speakers through one computer.From using in test bench facilities, data centers and help desks, to classrooms, and multi-media centers, the VGA Splitter & Extender with Audio delivers both performance and value by its video & audio signals to broadcast long distance up to 60 meter; good to cascade with daisy chained for additional displays.
Duplicates and amplifies VGA signal and Audio line out to monitors from computers.
Supports CRTs or flat screen displays.
Enhances video signals for long distance broadcast up to 60m.
Supports display resolution up to 2048 x 1536.
High Bandwidth : 450 MHz.
DDC/DDC2/DDC2B Plug & Play monitor support.
Supports stereo audio op / 2-CH Audio, bandwidth : 30 KHZ.
Cascadable connecting with daisy chained for additional displays.
Connectors:
Input : HD 15/F (Female) & 3.5mm Audio jack x 1 set.
Output : HD 15/F (Female) & 3.5mm Audio jack x 8 sets.
Made in Taiwan.


1 x VP118A
1 x DC 5V 2000mA Power Adaptor


Model
VP118A
Number Of Monitors Controlled
8 Monitors
Connector Port Video In 1 x HDB-15 Male
Video Out 8 x HDB-15 Female
Audio In 1 x Audio jack Female
Audio Out 8 x Audio jack Female
Power Port 1 x DC Jack
LEDs 1 x Power
Max Resolution 2048 x 1536 @ 70Hz
Signal Type VGA,SVGA,XGA
Connection Distance 60 m
Power DC 5V 2000mA
Physical Properties
Housing
Metal
Dimensions ( L x W x H )
215 x 85 x 45 mm
