[ VAS12 ] 2-Port VGA Video Switch & Extender with Audio & Remote
VAS12 dispays Video inputs from 2 computers on a single monitor or projector with Audio Function support. VAS12 is euipped with IR remote controller to control this VGA switch by 6 feet away. From use in test bench facilities, data centers and help desks, to classrooms, and multi-media centers, PANIO 2 ports VGA Switch & Extender with Audio & Remote delivers both performance and value.
Display video input from two computers on a single monitor or projector.
Can be used as the sharing device for projector.
PC selection via push buttons or IR remote control.
IR remote control allows you to switch outputs from up to 6 feet away.
Support Daisy-chain to expand the number of computers connection up to 3 layers.
Enhance video signal enhancement allows monitor to be placed up to 210 feet away.
Supports video resolutions up to 2048x1536.
Suitable for VGA, SVGA, XGA, SXGA, UXGA, and Multisync monitors.
Made in Taiwan.


1 x VAS12
1 x IR Remote Controller
1 x DC 5V 1000mA Power Adaptor
1 x User's Manual


Model
VAS12
Connector Ports
Video In
2 x HDB-15 Female
Video Out
1 x HDB-15 Female
Audio In
2 x Audio jack Female
Audio Out
1 x Audio jack Female
LEDs
Selected
2 ( Red )
ON-Line
2 ( Green )
Selection Method
Push Button or IR Remote Control

DDC, DDC2,DDC2B monitor

Yes (Max. Resolution up to 2048 x1536) @ 85Hz

Power
DC5V 1A
Environment
Operating Temp
0°C ~ 50°C
Storage Temp
-20 °C ~ 60°C
Humidity
0 ~80% RH, NC
Physical Properties
Housing
Metal
Weight
400 g
Dimensions ( L x W x H )
14 x 8.5 x 4.5 cm
