[ KF04 ] 4-Port PS/2&USB Combo Free A+ KVM Switch
PANIO 4 ports Combo Free A+ KVM switches ,KF04, allow you to control 4 computers via One VGA monitor , USB & PS/2 keyboard and mouse. You can connect this KVM to computers via signal Combo Cable through USB and/or PS/2 connection.This kvm supports Auto Scan and multiple platforms.
Console your Keyboard/Mouse via either way of PS/2 and/or USB arbitrarily.
Complex connections with PCs via either way of PS/2 and/or USB arbitrarily.
Controls 4 computers from a signal console (Keyboard/Mouse) over PS/2 and/or USB connections.
Supports Windows 98SE/ME/2000/XP/Vista/7/2003 Server, Linux, Mac OS9/OSX and Sun Micro System.
Emulates a keyboard on each PC to allow your computers to boot normally without a keyboard error.
Supports hot-swap. All devices connected to the KVM can be added or removed at any time, without shutting the unit down.
Supports 2 types of switching: (1) Hardware Push Button, (2) Hot-Keys on PS/2 and / or USB of keyboard arbitrarily.
Supports Auto-Scan function to alternate video between computers in preset intervals.
Supports LED display for PC status monitoring.
Supports VGA resolutions up to 2048 x 1536 @ 85HZ.
Supports Beeper during switching enabled.
Self powered through PS/2 and/or USB connection.
Fully compliant with the USB 1.1/ 2.0 specification.
May install to 19" racks (Need to purchase fitting)
Patent No. TW M 284961, DE 20 2006 002 295.3, ZL 2005 2 0132700.2



1 x KF04
4 x Combo Custom 4-in-1 cable ( 2 x PS/2 + USB + VGA) Cable
1 x User's Manual
1 x Rack Mount Kits (Optional Equipment)
1 x DC 5V 2A Power Adaptor (Optional Equipment)


Model/Function KF04
Port Selection Hotkeys / Push button
Console Ports
Video
1 x HDB-15 Female ( Blue )
Keyboard
1 x Mini Din-6 Female (Purple) ； 1 x USB TypeA Female (White)
Mouse
1 x Mini Din-6 Female ( Green )； 1 x USB TypeA Female (White)
Computer Ports
Video
4 x HDB-15 Female (Black)
Keyboard
Mouse
Scan Interval 5~250 seconds
LEDs
On Line/ Selected
 4 ( Orange )
Link
 4 ( Green )
Physical Properties
Housing
Metal
Weight
600g
Dimensions ( L x W x H )
21.5 x 8.5 x 4.5 cm
Environment
Operating Temp
 0~50°C
Storage Temp
 -20~60°C
Humidity
0~80% RH, Non-condensing


Step 1 Step 2 Action
[ Scroll Lock ]→[ Scroll Lock ] [ 1 ]→[ Enter ] or [ F1 ]→[ Enter ] Switch the active connection to PC 1
[ Scroll Lock ]→[ Scroll Lock ] [ 2 ]→[ Enter ] or [ F2 ]→[ Enter ] Switch the active connection to PC 2
[ Scroll Lock ]→[ Scroll Lock ] [ 3 ]→[ Enter ] or [ F3 ]→[ Enter ] Switch the active connection to PC 3
[ Scroll Lock ]→[ Scroll Lock ] [ 4 ]→[ Enter ] or [ F4 ]→[ Enter ] Switch the active connection to PC 4
[ Scroll Lock ]→[ Scroll Lock ] [ B ]→[ Enter ] Disable or enable beeper
[ Scroll Lock ]→[ Scroll Lock ] [ S ]→[ Enter ] Activate the Auto-Scan mode, default 5 sec
[ Scroll Lock ]→[ Scroll Lock ] [ S ]→[ 5-250 ]→[ Enter ] Select the Auto-Scan interval from 5 to 250 Sec
